名称:220V60Hz分体壁挂4P空调船用冷暧外贸空调 人气:3626


◇◆◇◆◇◆◇◆◇◆◇◆◇◆◇◆◆◇◆◇◆◇◆◇◆◇◆◇◆◇◆◆◇◆◇◆◇◆◇◆◇◆◇◆◇◆◆◇◆◇◆◇◆◇◆◇◆◇◆◇◆◆◇◆◇

BRAND ACB
Model        AUS-30H3-R2-A2
Power supply   Ph-V-Hz 1Ph-208-230V~60Hz
Cooling                         Capacity  W 7800
Capacity  tolerance %
Input  W 3450
Rated current   A 15.1
 EER   2.26
Heating                       Capacity  W 8800
Capacity  tolerance %
 Input  W 3400
Rated current   A 15.9
COP   2.59
Max. input consumption         W 4950
Max. current                A 22.6
Starting current                A 72
Compressor                Model    C-R191H6M
Type    Rotary
Brand    SANYO
Indoor Indoor air flow (Hi/Mi/Lo)     m3/h 1100/980/880
Rated input Power(cooling/heating) W 85
Rated current  (cooling/heating) A 0.38
Moisture Removal   (L/h) 3.8
Noise level(Hi/Mi/Lo) dB(A) 50/46/43
Unit dimension (W*H*D) mm 1080x330x220
Packing (W*H*D) mm 1180x425x300
Net weight   Kg 15
Gross weight   Kg 20
Outdoor Noise level  dB(A) 62
Unit dimension (W*H*D) mm 680x845x310
Packing   (W*H*D) mm 1010x765x430
Net weight   Kg 60
Gross weight   Kg 65
Refrigerant type       R22
Refrigerant charge g 2250
Design pressure              MPa 2.7
Refrigerant pipe    Liquid side mm Φ9.52
Gas side   mm Φ15.88
Max. refrigerant pipe length    m 20
Max. difference in level        m 10
Operation temperature range             -7~52
Ambient temperature range              -8~55
Application area           m2 27-48
